S1 Series Poppet Couplers
The S1 series ISO A couplers are the ideal choice where a tough, durable product of superior quality is required. They are perfectly suited to agricultural and industrial applications.
ISO 7241-A
Material: Steel Trivalent Plated
Valve: Poppet
Threads: BSP, NPT, Metric
S1Y Series C.U.P Poppet Couplers
The S1Y series ISO A couplings incorporate a pressure relief mechanism that enable them to be connected under pressure by hand.
ISO 7241-A
Material: Steel Trivalent Plated
Valve: Poppet-Connect Under Pressure
KZ Series Poppet Couplers
The KZ series couplers are a Chinese type for industrial and agricultural applications.
Material: Carbon steel with trivalent plating
Poppet valves prevent leakage when uncoupled
Locking ball system allows for quick connect and disconnect
Socket and plug machined from solid bar stock
S1 SS Series Poppet Couplers
The S1SS series ISO A couplers are the ideal choice where a tough, durable product of superior quality is required. They are perfectly suited to agricultural and industrial applications.
ISO 7241-A
Material: 316 Stainless Steel
Valve: Poppet
Threads: BSP Other Options on Request
S2 Series Steel Poppet Couplers
The S2 series ISO 7241-B couplers are the ideal choice where a tough, durable product of superior quality is required. They are perfectly suited to all types of industrial applications.
ISO 7241-B
Materials: Steel Trivalent Plated
Valve: Poppet
Threads: BSP, NPT
S2 Series Brass Poppet Couplers
The S2 Brass series ISO 7241-B couplers are the ideal choice where a tough, durable product of superior quality is required. They are perfectly suited to all types of industrial applications.
ISO 7241-B
Materials: Brass
Valve: Poppet
Threads: BSP, NPT
S2 Series 304 SS Poppet Couplers
The S2 304 stainless steel series ISO 7241-B couplers are the ideal choice where a tough, durable product of superior quality is required. They are perfectly suited to all types of industrial applications.
ISO 7241-B
Materials: 304 Stainless Steel
Valve: Poppet
Threads: BSP
S2 Series 316 SS Poppet Couplers
The S2 316 stainless steel series ISO 7241-B couplers are the ideal choice where a tough, durable product of superior quality is required. They are perfectly suited to all types of industrial applications.
ISO 7241-B
Materials: 316 Stainless Steel
Valve: Poppet
Threads: BSP, NPT
PBR Interchange Transport Couplers
The PBR couplers are essentially a high flow coupler for the transport industry, connection between truck and trailer.
PBR Interchange
Materials: Steel Trivalent Plated
Valve: Poppet - High Flow
Threads: BSP
TM Series Poppet Couplers
The TM series couplers are the ideal choice where a tough, durable product of superior quality is required. They are perfectly suited to all types of industrial and transport applications.
'Nordic Interchange'
Materials: Steel Trivalent Plated
Valve: Poppet
Threads: BSP
TC Series Poppet Couplers
TC series are used in high pressure applications with hydraulic and mechanical shock. Steel coupler sleeve and nipple are hardened for resistance to damage. Available in 3/8 size only. Sleeve lock is standard to guard against accidental disconnection. Applications include Hydraulic jacking & house moving, railway maintenance and construction equipment.
Materials: Steel Trivalent Plated
Valve: Poppet
Threads: NPT
10,000 PSI W.P.
1141 Series Threaded C.U.P. Coupling
1141 Series is a general purpose coupling that connects under pressure for high pressure applications. The 1/4” stainless steel coupling connects with a threaded brass sleeve.
Polyurethane seals resist extrusion and abrasion.
Threaded connect under pressure
Materials: 316 Stainless steel body, brass locking sleeve
Rated pressure 10,000 psi, 17,000 psi intermittent
